Place of Origin:
CHINA
Brand Name:
Delicacy
Certification:
CE
Model Number:
DP-83
|
Function
|
Dia. range
|
Height range
|
Max speed
|
|
Pre-necking ( For DR material)
|
45-73mm
|
90-320mm
|
400CPM
|
|
Necking + flanging
|
45-73mm
|
90-320mm
|
400CPM
|
|
seaming
|
45-73mm
|
90-320mm
|
400CPM
|
|
Capacity:
|
Tinplate thickness
|
Diam of copper wire
|
Welding speed
|
Welding frequency
|
|
500 cans/min
|
0.16-0.30
|
1.38mm or 1.50mm
|
9-57m/min
|
100-650hz
|
|
Can Dia
|
Can height
|
Can height
|
Overlap
|
Transformer Power
|
|
φ52-153
|
52-99
|
60-320mm
|
0.4mm
|
150Kw
|
|
Output frequency
|
Diameter
|
Max power
|
Cooling type
|
|
20-30Khz
|
52-180mm
|
1.5Kw/ heating coil
|
Air cooling / water cooling
|
Imported European high precision transducer, more reliable Equipped with temperature compensation system to improve accuracy With more humanized interface for operation With automatic height adjustment to make changeover more easy
1. Warranty: One year after shipment.
2. Delivery Time: 15-30 working days after receiving the advanced payment.
3. Power:3 phase 4 wire, 380V, 50Hz(or according to your requirements)
4. Installation and commissioning
Before installation,we will provide machine layout drawing with dimensions, total power, single power, power interface, water &air input and output position, total water consumption. After the machines arrived and have taken seat,you must connect the water and electric and air into the machines, then we shall send 1-2 technicians to install the production line.
