Automatic Tin Can Production Line For 1L 5L Small Rectangular Can

Automatic Tin Can Production Line For 1L 5L Small Rectangular Can

Tin Can Production Line Automatic

Tin Can Production Line 5L

Tin Can Production Line 1L

Place of Origin:

CHINA

Brand Name:

Delicacy

Certification:

CE

Model Number:

DP-004

Contact Us
Request A Quote
Product Details
Color:
Customized
Automatic:
Yes
Certification:
CE
Power(w):
35KW
Condition:
New
Warranty:
1 Year
After-sales Service Provided:
Engineers Available To Service Machinery Overseas,Online Support,Video Technical Support
Voltage:
380V/50HZ,380V,Customized,220V/380V,3phase 380V/220V/415V 50HZ
Type:
Tin Can Production Line
Product Name:
Automatic Small Rectangular Can Production Line
Payment & Shipping Terms
Minimum Order Quantity
1
Packaging Details
Wooden Box/ Customized
Delivery Time
30
Supply Ability
15SETS/Month
Product Description

Automatic Small Rectangular Can Production Line



1. INTRODUCTION TO SMALL RECTANGULAR CAN​



It is 3-pc can (mostly made of tinplate material) consisting of can body, lid and bottom. The can is rectangular shaped. The can capacity is generally 1-5L, diagonal 160-220mm, and height 120-360mm.

The cans can be used for various products like food, chemical, paint, edible oil, lubricating oil, medicine, etc.



2. BASIC SPECIFICATIONS AND PRODUCTION PROCESS OF SMALL RECTANGULAR CAN MAKING LINE:



The line is applicable for automatic production of 1L-5L rectangular cans.

Can height range: 80-350mm

Can diameter range: 50-190mm

Production capacity: 30-60CPM

Total power: about 70Kw

Floor space needed: about 100㎡

Manpower required: 3-4 workers

Technical workflow: body blank slitting – rounding – body welding – external welding seam coating – locating – expanding – top & bottom flanging – bottom seaming – turnover – top seaming – leak testing – packing.



3. THE LAYOUT OF THE PRODUCTION LINE​



Automatic Tin Can Production Line For 1L 5L Small Rectangular Can 0













4. ADVANTAGES OF AUTOMATIC SMALL RECTANGULAR CAN PRODUCTION LINE



The whole production line adopts automatic computer programming control system, fully realizing the automatic forming operations. Only 3-4 workers are needed to operate the entire line. The line is with high production speed, enhanced efficiency and low waste rate.

All stations of the whole production line are made by high hardness and wear-resistant materials. The guide rails and profiles are combined with precise coordination of servo motors to ensure a fast conveying system. Meanwhile, the seaming machine head adopts special design which has the feature of low noise and high efficiency. With -6wheel seaming machine head, the sealing quality is fast and stable.
